*This product was discontinued by the manufacturer and was replaced with a newer model Topcon RL-H5A Self Leveling Horizontal Rotary Laser
Topcon RL-H4C Rotary Laser Level is the best choice for the professional contractor who wants to make the extra investment to get the best performance in terms of range, accuracy, durability, battery life, and warranty.
Since the Topcon laser level has a higher IP Rating and longer warranty than most every other rotary laser level, it is likely to last longer, meaning an extra investment up front might actually save you money in the long run.
Topcon RL-H4C is considered the best rotary laser level on the market.
Topcon RL-H4C Review Summary
- Features
- Quality
- Price
- Laser Color: Red
- Leveling Type & Range: Self-Leveling, +/- 5 degrees
- Accuracy: +/- 1/16 inch @ 100 ft
- Range with Detector: Up to 2,600 ft
- Rotational Speed: 600 rpm
- IP Rating: IP66
- Power Supply: (4) D batteries
- Average Battery Life: 100 hours (D Cell) or 60 hours (Ni-MH option)
- Warranty: 5 Year Limited Warranty
- Top Features: Horizontal electronic self-leveling, height of adjustment alert, slope matching, LCD display, low battery indicator
Pros & Cons
- High accuracy
- Impressive battery life
- Incorporated with advanced technology: self-leveling, slope matching, anti-drift system
- Significant long term warranty
- A bit pricey but you pay for the quality
Special Features of Topcon RL-H4C
The Topcon RL-H4C Rotary Laser is best suited for certain situations, and has a variety of features that set it apart from its competitors:
***High Range and Accuracy
The Topcon Rotary Laser is capable of producing a diameter of 2,600 feet when used with a receiver.
It is accurate up to 1/16 of an inch at 100 feet. This is accurate enough for all but the most technical of jobs.
***Convenient Electronic Self Leveling
This feature matches its name exactly - the laser levels itself, automatically, meaning a lot less work for you.
***Easy Manual Slope Calibration
The Topcon RL-H4C Rotary Laser also allows for easy manual slope manipulation. Simply press a button and the laser will change its slope in the direction desired.
When it senses the receiver you have placed on the slope you want, the level will alert you.
***Impressive Durability
The Topcon RL-H4C has a near perfect IP rating of 66. This means the machine is "dust tight" and protected against heavy seas or powerful jets of water, making it a top rated outdoor laser level.
***Significant Long Term Warranty
The Topcon rotary laser has a 5-year warranty, one of the longest of any rotary level available on the market today.
Incredible durability combined with a long warranty means the Topcon laser is guaranteed to provide professional quality services for many years.
***Useful Anti-Drift System
Working on a jobsite with lots of vibrations?
That is no problem for the Topcon RL-H4C.
If the level is jarred or tilted while rotating, the anti-drift system, which Topcon calls its "HI Alert System", warns you with three flashing LED lights and a sensor's icon to prevent false readings.
***Long Battery Life
The Topcon has an astounding 100 hours of battery life from 4 D Cell batteries.
Topcon also sells rechargeable batteries and a AC/DC converter that can accompany the RL-H4C, meaning there are three different ways to power the machine.
This power versatility could prove critical on the job site if one or two power methods fail for some reason.
Benefits When Using The Topcon RL-H4C
Versatility
The Topcon can perform any task the professional contractor may come across.
It is one of the most accurate laser levels available on the market, and thus can perform tasks that require a tremendous degree of accuracy.
Long Range
The Topcon RL-H4C also possesses one of the longest ranges on the market, making it the ideal choice for large surveying jobs and construction projects.
This potent combination of range and accuracy means the Topcon Rotary Laser can fulfill all your laser level needs at the highest quality professional level.
Portability
The Topcon can be easily transported by just one person considering it weighs only 5.3 pounds and has dimensions of 7.0 x 8.5 x 7.7 inches.
See also:Best Digital Levels For Builders
Applications of Topcon RL-H4C Rotary Laser Level
Topcon RL-H4C Rotary Laser Level is best suited for large scale general construction projects such as grading, excavating, digging and laying a foundation in concrete.
This is because of its massive range and easy slope control, without which many grading projects would be impossible.
It is also ideally suited for jobs that demand a high degree of accuracy, like excavating and laying the foundation of a house or aligning fence posts. Topcon RL-H4C Rotary Laser is among the best outdoor laser levels.
It is also perfectly capable of completing more mundane tasks people often face inside the house, like hanging windows correctly, identifying studs before hanging shelves or cabinets.
See also:How to Use A Laser Level For Grading
How To Set Up The Topcon RL-H4C
In searching on how to set up this rotary laser level, I have found a very helpful video guide from a Topcon partner in Australia which is also applicable to Topcon RL-H4C products in the US. Check it out!
Click here to check Topcon RL-H4C price
Conclusion
If you are a professional contractor that likes to make the extra investment of money to get top quality performance out of your tools, then the Topcon RL-H4C Rotary Laser is likely your best option out of rotary laser levels available on the market today.
It has impressive features like tremendous range, battery life and easy slope manipulation, as well as having incredible durability and one of the biggest warranties in the field.
